The AHP-55 Oily Water Media Filter From Ecologix Environmental Systems LLC

Understanding the critical role of pH in effective water purification.

Published: 8/26/2025 by Tom McKinney oil water separatorsorganoclay

Ecologix Environmental Systems manufactures an oily water filter with oil removal technology designed for wastewater treatment, called the AHP-55 Liquid Phase Vessel. It's used primarily for removing trace floating oil droplets and sheens from water primarily as a polishing media for water treated by an oil water separator. This vessel is often used as a pre-treatment step before other carbon vessels to extend their lifespan.

Where small amounts of oil need to be removed from water at lower flow rates, the AHP-55 serves well as a primary oil water separation solution.

Key Features and Specifications

The AHP-55 is built with durability in mind, featuring heavy-gauge domed steel with a powder-coated exterior and dual internal liners. This design prevents bulging, leaking, or rusting. A key feature is the inclusion of a 30-psi pressure relief valve and ports for sampling and pressure monitoring.

  • Construction: Heavy-gauge, powder-coated steel with dual interior liners.
  • Media: The vessel is charged with Ecologix's proprietary OrganoClay media (MCM-830P), a non-swelling modified clay mineral.
  • Contaminant Removal: It effectively removes a wide range of hydrocarbons, oils, and trace amounts of heavy metals.
  • Flow Rate: It has a maximum flow rate of 27 GPM.
  • Pressure: The vessel has a maximum operating pressure of 30 psi.
  • Inlet/Outlet: It uses 2-inch inlet and outlet connections.
  • Media Capacity: It holds 200-250 lbs of OrganoClay media.

How It Works

The AHP-55 uses OrganoClay media, which is a modified clay mineral that adsorbs contaminants like oil and grease. Unlike some other filter medias, Ecologix's OrganoClay doesn't swell, which helps prevent the filter bed from blinding and allows it to operate for longer periods without needing a blend with anthracite filler for porosity.

Applications and Context

This vessel is part of Ecologix Environmental Systems' broader line of oil/water separators and wastewater treatment solutions. It's particularly useful for treating water with small amounts of oil before further filtration. Ecologix's products serve a variety of industries, including automotive, manufacturing, food and beverage, and mining, where oily wastewater is a common concern.
